Luna Victory Z series / CX3

Range up to 43,5 km
Up to 15 km/h
113 kg

MDR Class I (2017/745/EU) Medical Device

A modular scooter that’s ready for the future

Our all new Luna Victory Z is ready for the future; with its extremely high durability and premium quality this is the scooter that can and will fit all your needs. Designed for a 10-year life cycle, this commercial-grade quality scooter is exceptionally reliable. This state-of-the-art scooter offers maximum flexibility; with different configurations to match exactly what the end-user needs. The modularity combined with low maintenance forms the perfect scooter for a fleet owner.

This product is currently out of stock and unavailable.

Specifications

Model Luna Victory Z1
Luna Victory Z2
Luna Victory Z3
Model Number(s) Z1: SC123
Z2: SC133
Z3: SC143
Weight capacity 159 kg
Maximum speed Up to 15 km/h
Ground clearance 90 mm at motor
Turning radius 1257 mm
Length 1425 mm
Width 670 mm
Tires 13” pneumatic or solid, front and back
Drive system Rear-wheel drive, sealed transaxle, 24-volt DC motor
Braking System Regenerative and electromechanical
Range per charge Up to 43,5
Standard seat Type: High Back
Material: Black Vinyl
Battery Requirement(s) Quantity: 2
Type: Sealed lead-acid, deep cycle
Size: 50 or 75 Ah
Battery charger Up to 8 Amp, off-board

Overview

Download our
product brochure

Download our product brochure here to get an overview of our product range!

    You can opt-out anytime. View our privacy policy here.
  • This field is for validation purposes and should be left unchanged.

Features

  • Maximum configuration flexibility
  • Designed to maximize longevity
  • Comfortable dual suspension
  • Optimized for reconditioning
  • Maximum speed can be set between
  • 10, 12 and 15 km/h, without programming
  • Front basket standard
  • Push pull or gas throttle lever
  • 99% of all maintenance can be carried out within 20 minutes
  • Protective bumpers all-round
  • Motor protection program
  • Connected Data Monitoring (optional)
  • Steering wheel with push-pull lever or gas throttle switches
