Fusion

Range up to 25 km
Up to 6,4 km/h
74 kg

MDR Class I (2017/745/EU) Medical Device

Rear-wheel drive with high functionality

The Fusion rear-wheel drive power chair delivers aggressive, terrain-gripping torque and is available with an optional top speed of up to 10 km/h. The innovative, compact design of the Fusion makes it highly manoeuvrable in tight spaces without sacrificing traditional rear-wheel-drive performance.

Clear

Specifications

Weight capacity 136 kg
Maximum speed Up to 10 km/h
Range per charge 25 km
Ground clearance 114 mm
Overall length 890 mm
Overall width 635 mm
Turning radius 533 mm
Standard controls PG VR2 controller
Total weight (without batteries) 73,9 kg
Seating Tension-adjustable, sling back plus solid seat pan
Drive wheels 14" pneumatic
Castor wheels 9" pneumatic
Drive train Rear-wheel drive
Batteries Two 12-volt, deep cycle
Size: 2x 50 AH
Battery weight (each) 17 kg
Brakes Intelligent braking, electromagnetic regenerative, disc park brake

Overview

Download our
product brochure

Download our product brochure here to get an overview of our product range!

    You can opt-out anytime. View our privacy policy here.
  • This field is for validation purposes and should be left unchanged.

Features

  • Narrow 635 mm width and compact 890 mm length
  • Outstanding tight space maneuverability
  • Maximum speed up to 10 km/h
  • High-performance, high-efficiency motor package
  • Uniquely designed seating system is integrated with the base
  • Emark lighting package standard
  • Swing-away joystick
